8-338069-2

Product Name 8-338069-2

Manufacturer TE Connectivity AMP Connectors

Describe CONN RCPT 12POS 0.1 TIN SMD

Classification: Headers, Receptacles, Female Sockets

Datesheet DDEController?Action=srchrtrv&DocNm=338069&DocType=Customer+Drawing&DocLang=English

Stock 9999

Customer Reference

CONN RCPT 12POS 0.1 TIN SMD

9999 In Stock

More quantities are on the way.

Product Attributes

Type PARAMETERS

Style

Board to Board or Cable

Mounting Type

Surface Mount

Contact Finish - Mating

Tin

Pitch - Mating

0.100" (2.54mm)

Package

Tape & Reel (TR)^^Cut Tape (CT)

Operating Temperature

-40°C ~ 105°C

Number of Positions

Number of Rows

Contact Type

Forked

Insulation Color

Red

Current Rating (Amps)

Insulation Material

Polyamide (PA46), Nylon 4/6, Glass Filled

Row Spacing - Mating

0.100" (2.54mm)

Contact Length - Post

Material Flammability Rating

UL94 V-0

Mated Stacking Heights

Contact Shape

Mfr

TE Connectivity AMP Connectors

Number of Positions Loaded

All

Insulation Height

0.209" (5.30mm)

Voltage Rating

100VDC

Features

Pick and Place

Series

Micro-MaTch

Connector Type

Receptacle

Contact Finish - Post

Tin

Ingress Protection

Product Status

Active

Termination

Solder

Fastening Type

Friction Lock

Contact Material

Phosphor Bronze

Contact Finish Thickness - Post

Contact Finish Thickness - Mating

Applications

Automotive, General Purpose

Base Product Number

338069
